Methods to Remove and Install a Motorcycle Battery

In daily life, some people don’t know how to remove a battery from motorcycle when motorcycle lithium battery need to change. In fact, it is a simple process, and you may do it yourself own at home. In this article, we will tell the methods about how to remove and install a motorcycle battery.

Reading service manual

In general, there is a service manual to introduce about how to remove and install battery with factory instruction. If you can find it, you may read it carefully before acting, which can help you to access battery quickly and finish all process. And then you prepare the tools what you need to use.

Finding the battery

According to the guide of manual, you may first find the placement of battery. Of course, the placement of battery is different according to different types of motorcycle. For example, usually it is under the fuel for Yamaha YZF-R6 and FZ6. But for Yamaha FJR1300, it is inside the upper right fairing. For Harley shovelhead, it hangs way off the right side of the motorcycle. Generally speaking, it is on the tail section or hidden between the primary pulleys or under the motorbike leather seat. So, reading service manual of factory is needful.

Removing battery

Before you remove the battery, remember to disconnect the negative cable to ensure the safety. And then check the ends of the negative battery cable. Usually the negative and positive side are marked on the battery with “-“and “+”sign. You may find it easily and it can help you to avoid confusion when you install new motorbike battery on vehicle. And then you work on the negative end, but make sure that you try to decrease the possibility of grounding out the battery.

Next, you remove the positive cable. Usually this cable is red color, but not definitely. You may identify it by “+”mark. Now you may remove the hold-downs retaining the battery. Reminder that the hold-downs may be different, some are rubber straps, some are formed metal pieces, and some are foam blocks. After you get them out, you can remove the battery.

Installing motorcycle battery

After you remove the battery of motorbike, you may install new battery. Of course, you had better to check the motorcycle battery size and motorcycle battery power firstly. And check the positive and negative sides to make sure their correct direction when installing. Don’t make the terminals reverse and remember to examine it after installing new motorbike battery.

Some battery needs to be filled with acid. So, you should be careful to fill it to avoid the acid to be spilled on your motorbike. Next step is to hook up the cables. First of all, attach the positive cable before attaching the negative one. This installation is the reverse of removing battery, so please pay more attention to the order. Otherwise, it will cause hazards, such as motorcycle electrical components will be fired, or fuses will be popped. After you finish all, the last step is to test it.
